    DA series 0.25a 50v red plastic right angle spdt dip switch 3 buyers

    Ask Lasest Price
    Brand Name : KKG
    Model Number : DPL-08
    Price : Negotiate
    Payment Terms : T/T, L/C, Western Union
    Delivery Time : 15 - 20 days
    Certification : RoHS
    • Product Details
    • Company Profile

    DA series 0.25a 50v red plastic right angle spdt dip switch 3 buyers

    Black 3 Position PIANO Type SPST 2.54mm Pitch SMD Gull Wing DIP Switch

    Waterproof Electronic Dip Switch 8 Position 5P Single Pole Single Throw 2.54 Pitch Piano Type Dip Swit

    DIP switches are an alternative to jumper blocks. Their main advantages are that they areavailable in

    non-DIP surface-mount package types. They are, however, still referred to as "DIP switches", as the

    term has become associated with the style of switch.


    DIP switches'n Features


    1 Multiple Occasions, with multi-gear structure design, switch slide power evenly, good sense of paragraph
    2 Fire Retardant, UL94-V0 injection molding, strong pressure resistance
    3 Link Contacts, small contact resistance, reliable and stable

    4 Appearance is clean, solid and stable
    5 Convenient installation


    DIP Switch's Specification


    MECHANICAL
    1).Operation Force1000gf max.
    2).Stroke2.00mm
    3).Operation Temp-40deg C to 85deg C
    4).Storage Temp-40deg C to 85deg C
    5).Positions3 position
    ELECTRICAL
    1).Electrical Life2000 operations cycles
    2).Non-Switching Rating100mA, 50VDC
    3).Switching rating25mA, 24VDC
    4).Contact Resistance50mOhms max. at initial;100mOhms max.after life test.
    5).Insulation Resistance100MOhms,500VDC
    6).Dielectric Strength500VAC/1 minute
    7).CircuitSPST

    DA series 0.25a 50v red plastic right angle spdt dip switch 3 buyers


    Dip switch as a manual operation of a micro switch, dip switch in communication, security and many other

    equipment products are widely used. There are two pins ON the back of each key corresponding to the dip

    switch, to the ON side, then the following two pins through; Otherwise disconnect. These four keys are

    independent and have nothing to do with each other. This type of device is mostly used for binary coding.



    KKG electric CO.,LTD. is a company devotes itself to researching and manufacturing the components

    such as switches, sockets and connectors. The Production of Products mainly used in computer products,

    consumer electronics, electrical & electronics, industrial equipment & components......


    So far,KKG set up own factory ,Processing factory,OEM factory and sales company in mainland China,

    Taiwan(China) and Hong Kong .

    During this time, the company had won many awards. Just like the industry first prize for the ISO9001

    and the quality management.



    1 More than 2,000 models of switches and sockets.

    2 Monthly production capacity: 30 million pieces.

    3 MOQ: 5,000pcs, it’s negotiable.

    4 Good quality with competitive price.

    5 We can offer free samples with shipping and taxes pay by the buyer.

    6 Various operation force, height, and color for your choice.

    7 The discount depends on your order quantity.



    Q1.Are you a factory or trading company?

    A1.We are a factory, we can guarantee our price is first-hand, very cheap and competitive.


    Q2.How does your factory do regarding quality control?

    A2.All the products will be 100% checked before the shipment.


    Q3.When can I get the price?

    A3.Usually we quote within 24 hours after we get your inquiry.


    Q4.How could I get a sample?

    A4.if you can not buy our product in your local area, we will ship a sample to you.You will be charged

    a sample price plus all related shipping costs. Express delivery charge depends on the quantity of the

    samples.


    Q5.What is the price of shipping?

    A5.Depending upon the port of delivery, prices varies.


    6.Do your products come with waranty?

    A:Yes,we promise 1-3 year waranty according to different model.
