1mA 5V Dc Micro Detectors Sensor , Copper SMT Motion Detection Switch

    Buy cheap 1mA 5V Dc Micro Detectors Sensor , Copper SMT Motion Detection Switch from wholesalers

    Buy cheap 1mA 5V Dc Micro Detectors Sensor , Copper SMT Motion Detection Switch from wholesalers
    • Buy cheap 1mA 5V Dc Micro Detectors Sensor , Copper SMT Motion Detection Switch from wholesalers

    1mA 5V Dc Micro Detectors Sensor , Copper SMT Motion Detection Switch

    Ask Lasest Price
    Brand Name : KKG
    Model Number : DS-007SA
    Certification : CE / SGS / ISO9001
    Price : Negotiate
    Payment Terms : T/T, L/C, Western Union
    Delivery Time : Negotiate
    • Product Details
    • Company Profile

    1mA 5V Dc Micro Detectors Sensor , Copper SMT Motion Detection Switch

    1mA 5VDC SMT Push Restoration Switch , 50uA 3V DC Micro Motion Detector Switch

    Rating:1mA 5VDC~50uA 3V DC

    Temperature:-25~80℃
    Contact Resistance:2Ω max~5 Ω max

    lnsulation Resistance:100MΩ min(100V DC)

    Life:50,000Cycles


    Item Name
    Micro Switch DS-007SA
    Brand
    KKG
    Housing
    ABS
    Material
    Copper/Iron, Plastic
    Certification
    RoHS
    Temperature
    -25~80C
    Withstand Voltage
    AC500V(50Hz)/min
    Max. Voltage
    DC 30V 0.1A
    Contact Resistance
    ≤0.03Ω
    Insulation Resistance
    ≥100MΩ
    Actuating Force
    5~35N
    Life
    >50000 cycles
    MOQ
    10pcs
    Port
    Dongguan



    Our advantage​

    1. Manufacture experience: 10-year experience in this field.
    2.Quality assurance: All the products will go through lots of tests carefully before dispatch.
    3. Competitive production capacity and fast shipping.
    4. Manufacturer's price: Factory direct sale, most competitive price.
    5. We provide OEM/ODM service, If you have unique design, we can handle the whole development
    from outlook design, mechanical structure, electronics design and open the mold.

    About Shipping:

    1.We ship items by DHL/FEDEX/UPS/EMS/TNT,ETC.,you can choose by yourself.

    2.We hope goods arrive on time,but since this is an international delivery,shipping time will be highly depended on the courier company and local customs/duties.Thank you for your kindly understanding.


    FAQ


    Q: How can I get the quotation & drawing of the products ?
    A: Please tell us the requirement of product you need, we will provide drawing and quotation of the part related.

    Q: How about your quality control?
    A: We have the strict quality control system, and all goods must be 100% inspected before shipment.

    Q: Can I get the free sample before order.
    A: Sure, we will provide free sample for your testing if need, but shipping cost shall be borne by customer.
